| Number of cores | 3 None |
|---|---|
| Suitable as telephone cable | False |
| Colour outer sheath | Yellow |
| Material core insulation | Polyvinyl chloride (PVC) |
| UV resistant | True |
| Longitudinal water blocking cable | True |
| Radial water blocking cable | True |
| Suitable as computer data cable | True |
| Suitable as signalling cable | True |
| Core identification | Colour |
| Conductor category | Class 2 = stranded |
| AWG size | 18 AWG |
|---|---|
| Stranding element | Triple |
| Material outer sheath | Polyvinyl chloride (PVC) |
| Cable rating | UL AWM style 2661 VW-1 105°C @ 300V, CSA AWM A/B I/II 80°C @ 300V FT1, UV oil and water resistant |
| Cable geometry | Round |
| Screen over stranding | None |
|---|---|
| Cable length | 50 m |
| Color code | Automotive |
| Type of cable | PVC cable, yellow, unshielded, 18 AWG |
| Stranding | Bundle |
| Cable spool | Cable only |
| Operating temperature | -20 °C |
|---|
Sales Info
| Repairable | NOT_REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 22.352 |
| Lead Time | 28 |
| Dimension Width | 21.59 |
| Dimension Length | 21.59 |
| Stock Status | NON_STOCKED |
| Weight | 3.706 |
| Weight Unit | KG |
| Dimension Unit | CM |
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
| Technical Data | 889-td002_-en-p | 889-TD002 |
