| Housing Material | Standard Materials |
|---|---|
| Wire Size and Type | 22 AWG PVC |
| Type of mechanical accessory/spare part | Other |
|---|---|
| Panel mount thread size | 1/4 in 18NPT |
| Connector type | AC micro dual key |
| Connector insert material | Nylon |
| Number of pins | 3-pin |
| Receptacle shell material | Brass with nickel |
| Enclosure type rating | NEMA 1, 3, 4, 6P and IEC IP67, IP68, IP69K |
| Contact material | Gold-plated brass |
| Assembly rating | 250V @ 4A |
| Wire insulation | Oil-resistant PVC, 22 AWG stranded copper, 300V, UL recognized and CSA certified |
| Connector style | Straight male |
| Type of electrical accessory/spare part | Connecting cable |
|---|---|
| Wire size and type | 22 AWG, PVC |
| Color code | IEC or US or Auto |
| Conductor length | 0.3 m |
|---|
| Operating temperature | -40 °C |
|---|
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Visit the Technical Documentation Center
Search the Literature Library
Looking for more Technotes?
Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.
Search Knowledgebase
Technical Specifications
| Housing Material | Standard Materials |
|---|---|
| Wire Size and Type | 22 AWG PVC |
| Type of mechanical accessory/spare part | Other |
|---|---|
| Panel mount thread size | 1/4 in 18NPT |
| Connector type | AC micro dual key |
| Connector insert material | Nylon |
| Number of pins | 3-pin |
| Receptacle shell material | Brass with nickel |
| Enclosure type rating | NEMA 1, 3, 4, 6P and IEC IP67, IP68, IP69K |
| Contact material | Gold-plated brass |
| Assembly rating | 250V @ 4A |
| Wire insulation | Oil-resistant PVC, 22 AWG stranded copper, 300V, UL recognized and CSA certified |
| Connector style | Straight male |
| Type of electrical accessory/spare part | Connecting cable |
|---|---|
| Wire size and type | 22 AWG, PVC |
| Color code | IEC or US or Auto |
| Conductor length | 0.3 m |
|---|
| Operating temperature | -40 °C |
|---|
