| Degree of protection (NEMA) | 4X |
|---|---|
| Degree of protection (IP) | IP65 |
| Operating temperature | -25 °F |
| Storage temperature | -25 °F |
| List of degrees of protection (IP) | IP65, IP2X |
| List of degrees of protection (NEMA) | 4, 4X, 13 |
| Suitable for wall mounting | False |
|---|---|
| Suitable for ceiling mounting | False |
| First color selection | Green |
| Second color selection | Yellow |
| Housing base material | Polycarbonate, black |
| Mounting hole | 22.5 mm round mounting hole |
| Function | Two-color, half-lens illumination with barrier |
| Terminals | Plug-in terminal block, up to 2.5 mm² (14 AWG), IP2X |
| Mounting | Central mounting for bore holes 22 mm or 30.5 mm with hole adapter kit (catalog number 855P-AHA1) |
| Housing color | Black |
| Housing lenses | Polycarbonate |
| Type of current | AC/DC |
|---|---|
| Nominal voltage | 24 V |
| Flashing frequency | 2 Hz |
| Nominal current | 30mA @ 24V AC/DC, 50/60 Hz |
| With contact | False |
| Supply voltage range | ±10% |
| Turn-ON leakage current | ≥3 mA |
| Steady/flashing light | Externally by terminal connection |
| Lamp type | LED |
|---|---|
| Height | 49 mm |
| Weight | 40 g |
| Size | 30 mm diam |
| Mounting nut torque | 1.7 nm |
