800T-U62

30mm Potentiometer 800T PB

Name: 30mm Potentiometer 800T PB
Brand: Rockwell Automation
SKU: 800T-U62

Serial #:

Lifecycle status: Active

Description

30.5mm Potentiometer Unit, 3 Megohm Resistive Element

Unique Product Identifier	800T-U62
UPC	662073243960
Estimated Lead Time	37 days
Standard Warranty Duration	1 year See details
Country of Origin	Canada
EU Importer Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
EU Authorized Representative Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium

The information provided by Rockwell Automation on www.rockwellautomation.com (the “Site”) is for demonstration purposes only and may be incomplete or inaccurate. All information is provided “as is”, and Rockwell Automation makes no representations or warranties of any kind, express or implied, regarding the accuracy, adequacy, validity, reliability, or completeness of any information on the Site. Use of this information is at your own risk.

Type	30mm Potentiom

Terminations with finger safe covers	False
Enclosure compatibility (NEMA type)	1, 4, 12, 13
Hole diameter	30.5 mm
Suitable for illumination	False
Operator mechanical design life (cycles, min.)	25000
Operator function	Single turn
Vibration	10 G maximum
Potentiometer module termination wire range	14 - 18 AWG (x2)
Shock	100 G (no damage)
Potentiometer module termination tightening torque	6 - 7 in-lb / 0.7 - 0.8 N-m

Potentiometer module power rating	2 W
Potentiometer module input voltage	300V AC/DC (6V DC min)
Potentiometer module resistance rating	3.0 MegΩ
Type of electric connection	Screw connection

Operator construction/material	Metal
Operator cap/button shape	Round
Operator cap color	Black
Operator cap/button material	Plastic
Operator cap type	Standard knob
Operator type	Potentiom unit

Hazardous location rating	False
Humidity	50 %
Operating temperature	-25 °C
Storage temperature	-40 °C

Drawings
3D STEP Model (STP)	Download (ZIP)

Drawings
3D STEP Model (STP) Download (ZIP)

General	Publication
Push my Buttons Podcast	--
Repair Parts List	--
Product Cutsheet	--
Selection Guide	800T-BR012

Technical Data	Publication
800-td009_-en-p	800-TD009

Looking for more documentation?

Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.

Search the Literature Library

Eurasion Economic Community
CSA Listed
UL Listed
CE

This product was certified with the above certifications as of {}. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.

Items Per Page:

Technotes

Looking for more Technotes?

Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.

Search Knowledgebase

Overview

Unique Product Identifier	800T-U62
UPC	662073243960
Estimated Lead Time	37 days
Standard Warranty Duration	1 year See details
Country of Origin	Canada
EU Importer Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
EU Authorized Representative Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium

Technical Specifications

Type	30mm Potentiom

Terminations with finger safe covers	False
Enclosure compatibility (NEMA type)	1, 4, 12, 13
Hole diameter	30.5 mm
Suitable for illumination	False
Operator mechanical design life (cycles, min.)	25000
Operator function	Single turn
Vibration	10 G maximum
Potentiometer module termination wire range	14 - 18 AWG (x2)
Shock	100 G (no damage)
Potentiometer module termination tightening torque	6 - 7 in-lb / 0.7 - 0.8 N-m

Potentiometer module power rating	2 W
Potentiometer module input voltage	300V AC/DC (6V DC min)
Potentiometer module resistance rating	3.0 MegΩ
Type of electric connection	Screw connection

Operator construction/material	Metal
Operator cap/button shape	Round
Operator cap color	Black
Operator cap/button material	Plastic
Operator cap type	Standard knob
Operator type	Potentiom unit

Hazardous location rating	False
Humidity	50 %
Operating temperature	-25 °C
Storage temperature	-40 °C
