800MR-FXN6A7K

Push-Pull Single Unit 800MR PB

Name: Push-Pull Single Unit 800MR PB
Brand: Rockwell Automation
SKU: 800MR-FXN6A7K

Serial #:

Lifecycle status: Discontinued

Rockwell Automation announces that as of March 05, 2024, the Push-Pull Single Unit 800MR PB will be discontinued and no longer available for sale. Customers are encouraged to remove references to the affected product(s)

Discontinued Date: March 05, 2024 Replacement Category: Direct Replacement

Lifecycle status: Discontinued

Discontinued Date: March 05, 2024 Replacement Category: Direct Replacement

Description

800MR 3-Position Push-Pull Units, Non-Illuminated, OUT-Momentary CTR-Maintained IN-Momentary, Red, 1 N.C.L.B - 1 N.C, Large Screw Termination

Unique Product Identifier	800MR-FXN6A7K
UPC	662073412014
Estimated Lead Time	21 days
Country of Origin	United States of America

Suitable for illumination	False
Operator cap/button shape	Round
Illumination lamp type	Non-illuminated
Contact block type	NCLB
Illumination module type	Non-illuminated
Contact block thermal current rating	10 A
Illumination module input voltage	Non-illuminated
Contact block utilization category (AC)	300V @ 150V AC, 0.15A @ 8VA (logic reed)
Contact block utilization category (DC)	30V @ 0.06A, 1.8VA (logic reed)
Contact block operational voltage, max	AC 300

Hole diameter	22.5 mm
Operator mechanical design life (cycles, min.)	1000000
Contact block mounting style	Latch catridge
Operator type	Push-pull single unit
Enclosure compatibility	Type 13, IEC I44 IP65 oiltight
Contact block configuration	1 NC, 1 NC late break
Shock	100 G
Vibration	10 G
Contact block termination wire range	Accepts two #12 AWG (large screw)
Contact block durability	750000 ( standard contact), 200000 (logic reed)

Operating temperature	0 °C
Humidity	50% @ 40°C (104 °F)
Storage temperature	-40 °C

Termination style	Large screw
Operator cap color (lens)	Red

General	Publication
Product Cutsheet	--

Technical Data	Publication
800-td008_-en-p	800-TD008
