| Product Family | IEC |
|---|---|
| Terminal Type | Silver Bifurcated Contacts |
| Voltage type for actuating | DC |
|---|---|
| Interface | No |
| Rated control supply voltage at DC | 24 V |
| Rated control supply voltage at AC 50 Hz | 0 |
| Rated control supply voltage at AC 60 Hz | 0 |
| Mounting method | DIN-rail/screw |
| Switching capacity | Q600 @ DC per UL/CSA |
| Package quantity | Single pack (quantity of 1) |
| Rated thermal current (Ith) | Ambient temperature 60°C: 6A @ 24...240V, AC-12 |
| Electrical life cycle | 700000 @ 240V/2 A, AC-15 |
| With LED indication | No |
| Operating time, closing delay | 18 |
|---|---|
| Weight | 0.2 kg |
| Connection type | Spring clA connection |
| Operating time, opening delay | 6 to 12 ms |
| Wire size | Solid or coarse stranded for 2 conductors: 0.75...2.5 mm² |
| Suitable for manual operation | No |
Sales Info
| Repairable | NOT_REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 5.994 |
| Lead Time | 46 |
| Dimension Width | 4.902 |
| Dimension Length | 5.994 |
| Stock Status | NON_STOCKED |
| Weight | 0.209 |
| Weight Unit | KG |
| Dimension Unit | CM |
| Drawings | |
|---|---|
| 3-Dimensional STEP model (STP) | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| 3-Dimensional STEP model (STP) Download (ZIP) |
| Product Drawing Drawing (DXF) |
Sign in to your Rockwell Automation account to view and download technical drawings.
Sign In
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
| Technical Data | 700-td552_-en-p | 700-TD552 |
