1756-L915TPSXT

ControlLogix 5590 Process XT Controller

Name: ControlLogix 5590 Process XT Controller
Brand: Rockwell Automation
SKU: 1756-L915TPSXT

Serial #:

Lifecycle status: Active

Product at a glance

Repairable/Replaceable Calculate your impact

Product Registration

Description

ControlLogix 5590 Process XT Controller with Safety, 15 MB User Memory, 300 EtherNet/IP Devices, 5000 OPC/UA nodes

Lifecycle status: Active

Product at a glance

Repairable/Replaceable Repairable/Replaceable

Product Registration

Description

ControlLogix 5590 Process XT Controller with Safety, 15 MB User Memory, 300 EtherNet/IP Devices, 5000 OPC/UA nodes

Product Details

Unique Product Identifier	1756-L915TPSXT
UPC	197734628072
Estimated Lead Time	31 days
Standard Warranty Duration	1 year See details
Country of Origin	United States of America

Application	300 EtherNet/IP and 5,000 OPCU
Bulletin	1756
Communication	(2) 1GB EtherNet/IP ports amd
Display	4 Character Alpha/Numeric
Enclosure	None
Height	145.2mm (5.717 in)
Interface	USB C
Length	139.6mm (5.50 in)
Memory	15MB Standard/12MB safety
Mounting	1756 Chassis
Number Of Channels	2
Operating Temperature	-20...70C (-04...158F)
Power Supply	1.2A @ 5.1V DC / 5mA @ 1.2V DC
Processor	SIL2 Safety
Special Features	Conformal Coated + XT corrosio
Sub Brand	ControlLogix
Width	34.55mm (1.360 in)

Environmental Compliance	See Details \| Submit Inquiry
SVHC Information	View Guidance

boric oxide, diboron trioxide

CAS 1303-86-2

Item	Location	Concentration
1	Capacitors-ceramic multilayer capacitor	>0.1% w/w and <1.0% w/w
2	Resistors-general purpose metal film resistors	≤0.1% w/w
3	Resistors-general purpose metal film resistors	≤0.1% w/w
4	Resistors-general purpose metal film resistors	≤0.1% w/w
5	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
6	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
7	Resistors-general purpose metal film resistors	≤0.1% w/w
8	Resistors-general purpose metal film resistors	≤0.1% w/w
9	Resistors-general purpose metal film resistors	≤0.1% w/w
10	Resistors-general purpose metal film resistors	≤0.1% w/w
11	Resistors-general purpose metal film resistors	≤0.1% w/w
12	Resistors-general purpose metal film resistors	≤0.1% w/w
13	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
14	Resistors-general purpose metal film resistors	≤0.1% w/w
15	Resistors-general purpose metal film resistors	≤0.1% w/w
16	Resistors-general purpose metal film resistors	≤0.1% w/w
17	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
18	Resistors-general purpose metal film resistors	≤0.1% w/w
19	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
20	Resistors-general purpose metal film resistors	≤0.1% w/w
21	Resistors-general purpose metal film resistors	≤0.1% w/w
22	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
23	Resistors-general purpose metal film resistors	≤0.1% w/w
24	Resistors-general purpose metal film resistors	≤0.1% w/w
25	Resistors-general purpose metal film resistors	≤0.1% w/w
26	Resistors-general purpose metal film resistors	≤0.1% w/w
27	Resistors-general purpose metal film resistors	≤0.1% w/w
28	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
29	Resistors-general purpose metal film resistors	≤0.1% w/w
30	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
31	Resistors-general purpose metal film resistors	≤0.1% w/w
32	Resistors-general purpose metal film resistors	≤0.1% w/w
33	Resistors-general purpose metal film resistors	≤0.1% w/w
34	Resistors-general purpose metal film resistors	≤0.1% w/w
35	Resistors-general purpose metal film resistors	≤0.1% w/w
36	Resistors-general purpose metal film resistors	≤0.1% w/w
37	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
38	Resistors-general purpose metal film resistors	≤0.1% w/w
39	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
40	Resistors-general purpose metal film resistors	≤0.1% w/w

Cadmium

CAS 7440-43-9

Item	Location	Concentration
1	Pcmcia connectors-sd card connector	≤0.1% w/w
2	Pcmcia connectors-sd card connector	≤0.1% w/w
3	Pcmcia connectors-sd card connector	≤0.1% w/w
4	Pcmcia connectors-sd card connector	≤0.1% w/w
5	Connectors-modular connectors	≤0.1% w/w
6	Connectors-modular connectors	≤0.1% w/w
7	Connectors-modular connectors	≤0.1% w/w
8	Connectors-modular connectors	≤0.1% w/w
9	Connectors-modular connectors	≤0.1% w/w
10	Connectors-modular connectors	≤0.1% w/w

Lead oxide (lead monoxide)

CAS 1317-36-8

Item	Location	Concentration
1	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
2	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
3	Resistors-general purpose metal film resistors	≤0.1% w/w
4	Resistors-general purpose metal film resistors	≤0.1% w/w
5	Resistors-general purpose metal film resistors	≤0.1% w/w
6	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
7	Resistors-general purpose metal film resistors	≤0.1% w/w
8	Resistors-general purpose metal film resistors	≤0.1% w/w
9	Resistors-general purpose metal film resistors	≤0.1% w/w
10	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
11	Resistors-general purpose metal film resistors	≤0.1% w/w
12	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
13	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
14	Resistors-general purpose metal film resistors	≤0.1% w/w
15	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
16	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
17	Resistors-general purpose metal film resistors	≤0.1% w/w
18	Resistors-general purpose metal film resistors	≤0.1% w/w
19	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
20	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
21	Resistors-general purpose metal film resistors	≤0.1% w/w
22	Resistors-general purpose metal film resistors	≤0.1% w/w
23	Resistors-general purpose metal film resistors	≤0.1% w/w
24	Resistors-general purpose metal film resistors	≤0.1% w/w
25	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
26	Resistors-general purpose metal film resistors	≤0.1% w/w
27	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
28	Resistors-general purpose metal film resistors	>0.1% w/w and ≤100% w/w
29	Resistors-general purpose metal film resistors	≤0.1% w/w
30	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
31	Resistors-general purpose metal film resistors	≤0.1% w/w
32	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
33	Resistors-general purpose metal film resistors	≤0.1% w/w
34	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
35	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
36	Resistors-general purpose metal film resistors	≤0.1% w/w
37	Resistors-general purpose metal film resistors	≤0.1% w/w
38	Resistors-general purpose metal film resistors	≤0.1% w/w
39	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
40	Resistors-general purpose metal film resistors	≤0.1% w/w
41	Resistors-general purpose metal film resistors	≤0.1% w/w
42	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
43	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
44	Resistors-general purpose metal film resistors	≤0.1% w/w
45	Resistors-general purpose metal film resistors	>0.1% w/w and <1.0% w/w
46	Resistors-general purpose metal film resistors	≤0.1% w/w

Octanoic acid, pentadecafluoro-

CAS 335-67-1

Item	Location	Concentration
1	Pcmcia connectors-sd card connector	≤0.1% w/w

Triphenylphosphate

CAS 115-86-6

Item	Location	Concentration
1	Transformers-planar power supply transformers	>0.1% w/w and <1.0% w/w

General	Publication
Technical Detail	1756-TD001
Product Cutsheet	--

Selection Guide	Publication
1756-sg900_-en-p	1756-SG900

User Manual	Publication
1756-um900_-en-p	1756-UM900

Looking for more documentation?

Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.

Visit the Technical Documentation Center Search the Literature Library

Available Downloads

Firmware for ControlLogix 5590 (1756-L9) v38.011

See All Downloads

This product was certified with the above certifications as of 2026-07-27. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.

Looking for certification documents?
Explore certifications for this product and more in our comprehensive Literature Library.

Search the Literature Library

Regulatory Information

EU Importer Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
EU Authorized Representative Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
