| Supply voltage DC | 24 V |
|---|---|
| Operating current, max | 1 A |
| Rated current | 1 A fixed |
| Voltage type of supply voltage | DC |
| Degree of protection (IP) | IP20 |
| Width | 12.5 mm |
|---|---|
| Height | 98.5 mm |
| Weight per module | Approx. 0.13 lb |
| Terminal wire gauge | Push-in terminal PT10 AWG20... AWG8 (0.5mm² to 10mm²), Push-in terminal PT2.5 AWG24... AWG14 (0.14mm² to 2.5mm²) |
| Depth | 80 mm |
| Termination type | Push-in |
| No of channels | 1 None |
|---|---|
| Degree of pollution | 2 None |
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity / damp heat | 96 hr / 95% climate class 3K3 |
Sales Info
| Repairable | NOT_REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 5.715 |
| Lead Time | 5 |
| Dimension Width | 8.89 |
| Dimension Length | 2.54 |
| Stock Status | STOCKED |
| Weight | 0.118 |
| Weight Unit | KG |
| Dimension Unit | CM |
| Drawings | |
|---|---|
| 3-Dimensional STEP model (STP) | Download (ZIP) |
| 2-Dimensional Drawing (PDF) | Download (PDF) |
| Product Drawing | Drawing (DWG) |
| Drawings |
|---|
| 3-Dimensional STEP model (STP) Download (ZIP) |
| 2-Dimensional Drawing (PDF) Download (PDF) |
| Product Drawing Drawing (DWG) |
Sign in to your Rockwell Automation account to view and download technical drawings.
Sign In
| Type | Resource | Publication |
|---|---|---|
| General | Instructions for Standard 1694 Electronic circuit protection modules | 1694-IN002 |
| General | 1694 Specifications Technical Data | 1492-SG122 |
| General | Topics in Circuit Protection for Power Supplies | 1694-WP001 |
| General | Product Cutsheet | -- |
