1606-XLP90E-2

XLP Power Supply 90W 24VDC 3A

Name: XLP Power Supply 90W 24VDC 3A
Brand: Rockwell Automation
SKU: 1606-XLP90E-2

Serial #:

Lifecycle status: Active

Description

1606-XLP90E-2: Compact Power Supply, 24-28V DC, 90 W, 2-Phase 380-480V AC wide range Input Voltage

Preferred

Lifecycle status: Active

Description

1606-XLP90E-2: Compact Power Supply, 24-28V DC, 90 W, 2-Phase 380-480V AC wide range Input Voltage

Unique Product Identifier	1606-XLP90E-2
UPC	662074656813
Estimated Lead Time	141 days
Standard Warranty Duration	1 year See details
Country of Origin	Multiple

Sub Brand	Power Supply XLP

Adjustment range	24 V
Efficiency, typ	89.5 %
Hold-up time	>93 ms @ 480V AC
Input voltage	380...480V AC, 2-phase
Operational range	323...552V AC
Output voltage stabilized	True
Phases	2-phase
Power output	90 W
Rail mounting possible	True
Rated input current	<0.42A @ 400V AC
Rated output current	3.75A @ 24V
Secondary voltage adjustable	True
Special family function	No power boost
Special feature	NEC Class 2
Stabilized	True
Sub group	Compact family
Voltage type of supply voltage	AC

Mechanical

Degree of protection (IP)	IP20
Degree of protection (NEMA)	Other
Depth	103 mm
Direct mounting possible	False
Height	75 mm
MTBF	1594000 hr @ 40 °C, SN 29500
Shock	30 G, 6 ms 20G, 11 ms
Special functions	No special function
Type of electric connection	Spring ClA connection
Vibration	2 g
Wall mounting possible	True
Width	73 mm

Construction

Weight	360 g

Operating temperature	-10 °C
Relative humidity	<95%
Ripple and noise, max	50 mV
Storage temperature	-40 °C

Drawings
3D STEP model (STP)	Download (ZIP)
Product Drawing	Drawing (DXF)

Drawings
3D STEP model (STP) Download (ZIP)
Product Drawing Drawing (DXF)

Click the Download CAD button below to view all file formats available for download.

General	Publication
Short Circuit Ratings Data Sheet	--
Product Cutsheet	--

Technical Data	Publication
1606-td002_-en-p	1606-TD002

Looking for more documentation?

Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.

Search the Literature Library

This product was certified with the above certifications as of 2026-07-18. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.

Looking for certification documents?
Explore certifications for this product and more in our comprehensive Literature Library.

Search the Literature Library

Regulatory Information

EU Importer Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
EU Authorized Representative Address	Rockwell Automation N.V Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium
