| Construction |
Standard
|
|---|---|
| Data Transfer Rate |
100BASE-TX, 100 Mbit/s
|
| Second End Description |
Straight Male
|
| AWG-size |
22 AWG
|
|---|---|
| Voltage |
300 V
|
| Cable bandwidth |
100BASE-TX, 100 Mbit/s, IEEE 802.3 fast ethernet over copper wiring
|
| Cable rating |
(UL) CMX, CMR, c(UL) CMG, (UL) PLTC or AWM 2570 80°C @ 600V, TIA-568-B
|
| Length |
0.6 m
|
|---|---|
| Type of connector connection 1 |
M12
|
| Cable outer diameter |
8.13 mm
|
| Length, approx |
47 mm
|
| Crossover |
Standard
|
| Number of conductors |
4 conductors (2-pair)
|
| Secondary end connector |
Micro style QD, (D-code QD)
|
| Cable type |
Teal, foil shield, 600V PVC, 22 AWG
|
| Material |
Coupling nut: Nickel-plated brass, housing: polyurethane (PUR), contact: Gold-plated brass
|
| Material connector housing, connection 1 |
Plastic
|
| Special characteristic |
Standard
|
| Mounting |
Front-mount
|
| Bend radius |
10 x cable diam
|
| Degree of protection (IP) |
IP67
|
|---|---|
| Operating temperature |
'-20 to 80 °C
|
| Second end description |
Straight male
|
|---|---|
| First end description |
Straight male
|
| Drawings | |
|---|---|
| 3-Dimensional STEP Model (STP) | Download (ZIP) |
| Drawings |
|---|
| 3-Dimensional STEP Model (STP) Download (ZIP) |
| General | Publication |
|---|---|
| Product Cutsheet | -- |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Search the Literature Library
- CE
- UL Listed
This product was certified with the above certifications as of {}. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
| Technotes |
|---|
Looking for more Technotes?
Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.
Search Knowledgebase
Technical Specifications
| Construction |
Standard
|
|---|---|
| Data Transfer Rate |
100BASE-TX, 100 Mbit/s
|
| Second End Description |
Straight Male
|
| AWG-size |
22 AWG
|
|---|---|
| Voltage |
300 V
|
| Cable bandwidth |
100BASE-TX, 100 Mbit/s, IEEE 802.3 fast ethernet over copper wiring
|
| Cable rating |
(UL) CMX, CMR, c(UL) CMG, (UL) PLTC or AWM 2570 80°C @ 600V, TIA-568-B
|
| Length |
0.6 m
|
|---|---|
| Type of connector connection 1 |
M12
|
| Cable outer diameter |
8.13 mm
|
| Length, approx |
47 mm
|
| Crossover |
Standard
|
| Number of conductors |
4 conductors (2-pair)
|
| Secondary end connector |
Micro style QD, (D-code QD)
|
| Cable type |
Teal, foil shield, 600V PVC, 22 AWG
|
| Material |
Coupling nut: Nickel-plated brass, housing: polyurethane (PUR), contact: Gold-plated brass
|
| Material connector housing, connection 1 |
Plastic
|
| Special characteristic |
Standard
|
| Mounting |
Front-mount
|
| Bend radius |
10 x cable diam
|
| Degree of protection (IP) |
IP67
|
|---|---|
| Operating temperature |
'-20 to 80 °C
|
| Second end description |
Straight male
|
|---|---|
| First end description |
Straight male
|
Drawings
| Drawings | |
|---|---|
| 3-Dimensional STEP Model (STP) | Download (ZIP) |
| Drawings |
|---|
| 3-Dimensional STEP Model (STP) Download (ZIP) |
Documents
|
Product Cutsheet
General
-- |
| General | Publication |
|---|---|
| Product Cutsheet | -- |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Search the Literature Library
Certifications
- CE
- UL Listed
This product was certified with the above certifications as of {}. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
