| Degree of protection (NEMA) | 13 |
|---|---|
| Degree of protection (IP) | IP67 |
| Width sensor | 41.91 mm |
| Height of sensor | 74.93 mm |
| Length of sensor | 40 mm |
| Sensing mode | Light-/dark switching |
| List of degrees of protection (NEMA) | 4X, 6P, 12, 13 |
| Sensing mode type | Transmitted beam receiver |
| Sensing distance | Depends on transmitted beam emitter |
| List of degrees of protection (IP) | IP69K, IP67 |
| Vibration | 10...55 Hz, 1 mm Alitude, meets or exceeds IEC 60947-5-2 |
| Shock | 30 G with 1 ms pulse duration, meets or exceeds IEC 60947-5-2 |
| Operating environment | IP69K, IP67 with 1200 psi, NEMA 3, 4X, 6P, 12, 13, ECOLAB rated |
| Suitable for safety functions | False |
| Wavelength of the sensor | 880 nm |
|---|---|
| Response time | 2 ms |
| Voltage type | DC |
| Material housing | Plastic |
| Type of switching output | PNP/NPN |
| Setting procedure | Manual adjustment |
| Type of electric connection | Cable |
| Type of light | Infrared light |
| Scope of delivery of the one-way system | Receiver |
| Type of switch function | Other |
| Current consumption, max | 30 mA |
| Lens material | Acrylic |
| Load current | 250mA @ 30V DC |
| Connection type | 5 m, 300V cable |
| Protection type | Short circuit, reverse polarity, false pulse, overload |
| LED status | Yellow ON: power is ON |
| With time function | False |
| Pre failure notice | False |
| With reflector | False |
| Sensor types | Standard ON/OFF |
| Max. opening angle | 1.5 ° |
|---|---|
| Operating temperature | -34 °C |
| Relative humidity | 5 to 95 % |
| Ambient light immunity | Incandescent light 5000 lux |
| Material of optical surface | Plastic |
|---|---|
| Construction type housing | Special construction |
| Housing material | Valox® |
Sales Info
| Repairable | NOT_REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 5.994 |
| Lead Time | 24 |
| Dimension Width | 24.105 |
| Dimension Length | 24.003 |
| Stock Status | NON_STOCKED |
| Weight | 0.54 |
| Weight Unit | KG |
| Dimension Unit | CM |
