| Supply voltage DC | 24 V |
|---|---|
| Operating current, max | 3 A |
| Rated current | 3 A fixed NEC Class2 |
| Voltage type of supply voltage | DC |
| Degree of protection (IP) | IP20 |
| Width | 12.5 mm |
|---|---|
| Height | 98.5 mm |
| Weight per module | Approx. 0.13 lb |
| Terminal wire gauge | Push-in terminal PT10 AWG20... AWG8 (0.5mm² to 10mm²), Push-in terminal PT2.5 AWG24... AWG14 (0.14mm² to 2.5mm²) |
| Depth | 80 mm |
| Termination type | Push-in |
| No of channels | 2 |
|---|---|
| Degree of pollution | 2 |
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity / damp heat | 96 hr / 95% climate class 3K3 |
| Drawings | |
|---|---|
| 3-Dimensional STEP model (STP) | Download (ZIP) |
| 2-Dimensional Drawing (PDF) | Download (PDF) |
| Product Drawing | Drawing (DWG) |
| Drawings |
|---|
| 3-Dimensional STEP model (STP) Download (ZIP) |
| 2-Dimensional Drawing (PDF) Download (PDF) |
| Product Drawing Drawing (DWG) |
Sign in to your Rockwell Automation account to view and download technical drawings.
Sign In
| Type | Resource | Publication |
|---|---|---|
| General | 1694 Specifications Technical Data | 1492-SG122 |
| General | Product Cutsheet | -- |
| General | Topics in Circuit Protection for Power Supplies | 1694-WP001 |
| General | Instructions for I/O Link 1694 Electronic Circuit Protection Modules | 1694-IN001 |
