| Input Circuit Protection |
6 A Slow Blow Fuse or Cat. No. 1489-A1C060
|
|---|---|
| Input Voltage Range |
100-240V AC/110-150V DC
|
| Output Voltage Range |
12 -15V DC
|
| Nominal value output voltage 1 |
12 V
|
|---|---|
| Secondary voltage adjustable |
True
|
| Power output |
180 W
|
| Voltage type of supply voltage |
AC/DC
|
| Rated supply voltage at DC |
110 V
|
| Derating |
5 w/°c
|
| DC OK relay contact |
True
|
| Input inrush current limiter |
Active
|
| Output voltage |
12...15V DC
|
| Power factor |
0.92 typical
|
| Operational range |
88...188V DC
|
| Reserve power (typ. 4 s) |
22.5A @ 12V DC
|
| Rated output current |
15A @ 12V DC
|
| External input fuse, min |
B-6 A or C-4 A
|
| Power losses |
16.1 W typical
|
| Sub group |
Performance family
|
| Hold-up time |
32 ms
|
| Efficiency |
91.8% typical
|
| Input inrush current |
4 A/7 A
|
| Input voltage |
100...240V @ AC, 47...63 Hz
|
| Rated input current |
1.65A @ 120V AC
|
| Special feature |
Active PFC, Class 1 division 2, semi F47, 9) ABS/GL/RINA (marine)
|
| Output voltage stabilized |
True
|
| Rail mounting possible |
True
|
| Stabilized |
True
|
| Height |
124 mm
|
|---|---|
| Depth |
117 mm
|
| Direct mounting possible |
False
|
| Width |
60 mm
|
| Degree of protection (IP) |
IP20
|
| Type of electric connection |
Spring clA connection
|
| Special functions |
No special function
|
| MTBF |
631 kh (40 °C, SN29500)
|
| Wall mounting possible |
True
|
| Degree of protection (NEMA) |
Other
|
| Ripple and noise, max |
50 mV
|
|---|---|
| Operating temperature |
-25 °C
|
| Lifetime, min |
76 kh (+40 °C)
|
| Non-operating temperature range |
-40 to 85 °C
|
| Weight |
930 g
|
|---|
| Drawings | |
|---|---|
| 3D STEP model (STP) | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| 3D STEP model (STP) Download (ZIP) |
| Product Drawing Drawing (DXF) |
Sign in to your Rockwell Automation account to view and download technical drawings.
Sign In
| General | Publication |
|---|---|
| Installation Instructions | 1606-IN015 |
| Product Cutsheet | -- |
| Technical Data | Publication |
|---|---|
| 1606-td002_-en-p | 1606-TD002 |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Search the Literature Library
- Eurasion Economic Community
- Australian RCM
- Semiconductor Inds Immunit
This product was certified with the above certifications as of {}. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
