| Connection type |
Switch body : glass-filled thermoplastic
|
|---|---|
| Efficiency |
-20
|
| Flicker |
10A @ 250V AC, 0.3A @ 250V DC per NEMA/EEMAC
|
| Fuse block option |
37 kW @ 500...600V AC, 3-phase, 50 Hz
|
| Hold-up time |
-40
|
| Individual harmonics (DC-127th) |
30Hp @ 600V DC per UL and CSA
|
| Interharmonics |
AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA min per IEC
|
| LED status |
10000
|
| Level-5 lens color |
2000 m per IEC 947-1
|
| NEMA rating designation |
60A @ 250/600V DC
|
| Operating distance |
2200V @ 1min
|
| Operational range |
200000A @ 600V AC : with class J or class R fuses
|
| Power losses |
2.5
|
| Rated input current |
Lug to terminal : 50 in-lb
|
| Rated output current |
600V @ 60A switch, 60 A type J fuse clips
|
| Special family function |
6
|
| Special product function |
Knife switch style handle
|
| Spot size |
90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1
|
| Sub group |
-20
|
| Temperature, max |
Protective cover
|
| Transient detect |
AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 5V @ 1mA min per IEC
|
| Number of auxiliary contacts as normally open contact |
1
|
|---|---|
| Number of poles |
3
|
| Rated permanent current Iu |
60 A
|
| Max. rated operation voltage Ue AC |
600 V
|
| Type of control element |
Long turning handle
|
| Switching frequency, max |
6 ops/m
|
| Continuous current rating |
60 A
|
| Number of switches |
1
|
| Motor drive optional |
False
|
| Voltage release optional |
False
|
| Type of electrical connection of main circuit |
Screw connection
|
| Switch and fuse rating (fusing) |
600V @ 60A switch, 60 A type J fuse clips
|
| Short circuit withstand capability |
200000A @ 600V AC, with class J or class R fuses
|
| KW rating, max |
37 kW @ 500...600V AC, 3-phase, 50 Hz per IEC (AC23)
|
| Hp rating, max |
7.5Hp @ 115V AC, 3-phase, 60 Hz per UL and CSA
|
| Auxiliary contact electrical ratings |
AC 15, DC 13 to IEC/EN60947-5-1 and UL 508, 17V @ 5mA minimum per IEC
|
| Electrical interlock ratings |
Standard contact 2 NO: 10A @ 250V AC, 0.3A @ 250V DC per NEMA/EEMAC
|
| With pre-assembled cabling |
False
|
| Dielectric strength |
2200V @ 1min
|
| Operating handle style |
Knife switch style handle
|
| Interlockable |
True
|
|---|---|
| Recommended torque |
Switch side: 45 in-lb
|
| Version as main switch |
True
|
| Factory option |
Threaded rod (19 in max.)
|
| Mechanical life operations |
10000
|
| Degree of protection |
Operating handles: painted Type 1, 3R, 4, 12
|
| Material |
Switches, mechanisms and accessory kits: Zinc-plated Steel, RoHS compliant finish
|
| Width |
6.81 in
|
|---|---|
| Device construction |
Built-in device fixed built-in technique
|
| Height |
8.58 in
|
| Depth |
3.63 in
|
| Altitude |
2000 m (6562 ft) per IEC 947-1
|
|---|---|
| Ambient temperature |
Storage: -40...65 °C (-40...149 °F)
|
| Relative humidity |
90% @ 20°C (68 °F) and 50% @ 40°C (104 °F) per IEC 947-1
|
