| Adjustment Type | Frame Only |
|---|---|
| IEC Breaking Capacity | 70kA @ 415V |
| Protection | Thermal Magnetic/Electronic |
| Standards Compliance | UL489, CSA22.2 No. 5, IEC 60947-2 |
| Current | 400 A |
|---|
| Drawings | |
|---|---|
| 2-Dimensional Drawing (PDF) | Download (PDF) |
| 3-Dimensional STEP model (STP) | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| 2-Dimensional Drawing (PDF) Download (PDF) |
| 3-Dimensional STEP model (STP) Download (ZIP) |
| Product Drawing Drawing (DXF) |
