Install and Run FactoryTalk View SE - FactoryTalk DataMosaix Connector (Manual‑Console)

Perform the following steps to install
FactoryTalk View SE - FactoryTalk DataMosaix
 connector:
  1. Download the Installer
    Obtain the
    FT View SE DataMosaix Connector
     installer file (
    FTDataMosaix_ViewSE_Connector.exe
    ) from the from the Product Compatibility and Download Center (PCDC).
  2. Prepare the Files
    Place the downloaded installer and the
    config.yml
     file in the same folder.
  3. Open Command Prompt
    Navigate to the folder where the files are located and open
    Command Prompt (cmd)
    .
  4. Run the Installation Command
    Execute the following command:
    <path-to-your-folder> "FTDataMosaix_ViewSE_ConnectorR1.0.0.exe" "config.yml"
  5. Connector Initialization
    After running the command, the FT View SE Extractor will start and perform the following actions:
    • Validate user authentication.
    • Upon successful authentication, connect to the specified application.
    • If no time-series tags are found, the extractor will automatically create one during the first run.
    FT View SE - DataMosaix Connector Initialization
